Upon opening the DWG file in AutoCAD and you went Zoom extents you only see the relevant drawing but as soon as you Do a Zoom All you can see that the drawing spanned too large an area for Revit to interpret the DWG correctly. The tread lines are jagged where it should be straight parallel lines.Īfter troubleshooting we found that the issue was with the DWG file. Have a look at arrow showing the architectural staircase in plan.
I recently came across an issue whereby the DWG geometry showed as jagged lines when imported into Revit as shown in the screenshot below.
